The Interra ITR830-1004 Mitsubishi Heavy Industries AC KNX Gateway is an air-conditioning interface for monitoring and controlling the functional parameters of Mitsubishi Heavy indoor units over the KNX bus. One side connects to the indoor-unit electronics on the Mitsubishi wired-remote communication bus (cable supplied per Interra datasheet); the other side connects directly to the KNX twisted-pair line for bidirectional integration with ETS, visualisation and hotel / residential BMS.

ITR830-1004 is the coding in the ITR830-X004 family that includes the digital / analog input connector (Interra marks these inputs as available on ITR830-1004). Compatible models are those listed in the Interra compatibility list (see Downloads). The gateway can be installed inside the indoor unit; Interra specifies a maximum AC-side cable distance of 350 m. It may operate alone or with an optional Mitsubishi wired remote in a documented master / slave arrangement. On-board 4 logic blocks and 8 converters support energy-saving routines, scenes and temperature limits. Ambient temperature for the AC can be taken from the gateway temperature input or from a KNX object; via 3 digital inputs, external devices can be connected. The AC unit reports error notifications on KNX for exceptional faults.

Key Features — Mitsubishi Heavy on KNX

• Bidirectional MHI integration: Monitor and control Mitsubishi Heavy operating parameters from KNX; Interra notes extra communication objects for project flexibility.
• Wired-remote bus connection: Connects to the AC indoor wired-remote communication terminal (cable supplied); optional wired remote with master/slave roles per Interra diagrams.
• Digital / analog inputs (1004): Temperature input and up to 3 digital inputs for external devices — the feature that distinguishes ITR830-1004 from ITR830-0004 (no digital-input coding).
• Logic & converters: 4 logical advanced parameters + 8 converter parameters for scenes, limits and energy logic in ETS.
• Fault feedback: AC error notifications published on the KNX bus.
• Compact, bus-powered: 88 × 62 × 27 mm (W × H × D); typical current consumption 5 mA; IP20; KNX certified; S-Mode commissioning; light grey.

At a Glance

Specification	Detail
Order code	ITR830-1004
AC brand / type	Mitsubishi Heavy Industries (per Interra compatibility list)
Dimensions (W × H × D)	88 × 62 × 27 mm
Bus current (typ.)	5 mA
AC cable distance (max.)	350 m (wired-remote bus)
Digital / analog inputs	Yes (ITR830-1004 coding)
Logic / converters	4 logic blocks · 8 converters
Configuration	ETS (S-Mode)
Protection / certification	IP20 · KNX Certified · CE

Applications and KNX Integration

• Hotels & residential: One gateway per addressed Mitsubishi Heavy indoor unit; pair with Interra room panels such as iX3 or iX2.
• Without digital inputs: Use ITR830-0004 when the DI/temperature-input connector is not required.
• Other brands on Smartanix: ITR830-0003 Daikin Sky & VRV, ITR830-0009 Gree VRF, ITR830-0014 Toshiba VRF, ITR830-0501 Samsung NASA, ITR830-1001 Mitsubishi Electric VRF.
• Bus power: Size the line with a suitable KNX supply (e.g. ITR900 640 mA) when many gateways share a segment.

Choosing and Commissioning

Always verify the indoor model against Interra’s official Compatibility List before ordering. Choose ITR830-1004 when you need the digital/analog input connector; choose ITR830-0004 when you do not. If a wired remote shares the bus, set gateway and remote master / slave roles as documented (when the remote is master, ambient temperature reference cannot be taken from the KNX bus). Commission with the Interra ETS application for the ITR830-X004 family (S-Mode). Full ratings, connection diagrams, input parameters and environmental limits are in the Datasheet and Product Manual under Downloads. Installation must follow Interra wiring rules and local electrical practice.
