The Interra ITR830-0004 integrates Mitsubishi Heavy Industries air conditioners with KNX for complete bidirectional monitoring and control. The gateway connects to the indoor unit wired-remote bus and the KNX line, reporting modes, setpoints, fan speeds, and fault codes to the building network.

Installation is typically inside the indoor unit or in a nearby enclosure. 3 digital inputs accept window contacts, occupancy sensors, or other binary devices for interlocks. Ambient temperature can be taken from the gateway sensor input or a KNX temperature object. 4 logic gates and 8 converters enable energy-saving scenes and temperature limits in ETS.

Key Features — Mitsubishi Heavy on KNX

• VRF / FD compatibility per Interra compatibility list (some units need optional SC-BIKN-E(A)).
• Master role when no wired remote; master/slave selectable when sharing the bus with MHI remote.
• Extra communication objects for flexible HVAC logic.
• Error notifications from the AC unit on KNX.

At a Glance

Specification	Detail
Order code	ITR830-0004
AC brand	Mitsubishi Heavy Industries
Digital inputs	3
Dimensions (W × H × D)	88 × 62 × 27 mm
Bus current (typ.)	5 mA

Applications and KNX Integration

• BMS / GRMS: Pair with iSwitch+ thermostats or iX3 panels for room UI.
• Mitsubishi Electric VRF: Use ITR830-1001 (different OEM protocol).
• Other gateways: ITR830-0013 Midea, ITR830-0006 LG.

Choosing Interra AC Gateways

Verify indoor unit model numbers against the compatibility list before purchase. ITR830-0004 is specific to Mitsubishi Heavy; do not substitute for Mitsubishi Electric City Multi gateways.
