The EAE RCU0808 KNX Room Control Unit is an all-in-one DIN-rail actuator for hotel rooms, apartments, and commercial spaces. Combines 8 × 16 A relay outputs with 8 galvanically isolated universal input channels in one module — ideal when conventional push-buttons or dry contacts must be wired alongside room actuation.

From a single module it controls lighting, blinds, fan coils, and optional dry-contact inputs where fitted. The RCU0808 is bus-powered (no external auxiliary supply required) and switches resistive, capacitive, and inductive loads in accordance with EN 60669, including fluorescent lamp loads at 16 A / 250 V AC.

Key Features — 8x16A Outputs + 8 Digital Inputs

Output Configuration

• 8 × 16 A relay outputs: Grouped into 2 independent output channel groups.
• Per-group modes: Switching (×4), AC blind (×2), DC blind (×1), 2-point valve (×2), 3-point valve (×1).
• Manual control: On-device manual override per channel.
• Switching rating: 16 A at 250 V AC — 6 × 10³ ops (resistive) per datasheet.

Universal Input Channels

• 8 galvanically isolated inputs: Each operates as a universal KNX interface.
• Switch / push-button input: Conventional wall switches and push-buttons.
• Shutter / blind control: Manual blind operation from standard inputs.
• Dimmer control: Analogue dimming commands from connected controls.
• Value transfer / pulse counter: Metering and pulse-count applications.
• Scene control: Scene recall from local buttons.
• Dry contact inputs: Card holders, window contacts, and other dry contacts.

Room Functions

• Light switch: On/off lighting control.
• AC/DC blind control: Shutter and blind positioning.
• Fan control: Ventilation switching.
• Fan coil control: 2- and 3-point valve HVAC control.
• Dry contact inputs: Card holder, window contact, and other dry inputs (where inputs fitted).

Logic Functions

• Staircase, external logic, priority, threshold, operating hour, sweep.

At a Glance

Specification	Detail
Product type	Room Control Unit — 8 outputs + 8 universal inputs
Order code	RCU0808 (SMP RCU0808)
Relay outputs	8 × 16 A
Universal inputs	8 galvanically isolated channels
Output channel groups	2 independent configurable groups
Load standard	EN 60669 (resistive, capacitive, inductive, fluorescent)
Power supply	KNX bus — no auxiliary supply required
Configuration	ETS — KNX Room Control Unit v2.0
Dimensions (H × W × D)	66 × 108 × 90 mm (6 MW)
Mounting	35 mm DIN rail (EN 60715)

Full electrical ratings are listed under Technical Specifications. Datasheet, product manual, installation manual, ETS application, and certificates are under Downloads.

Applications and KNX Integration

• Hotel guest rooms: Central room controller for lighting, blinds, and fan coil — ideal for GRMS integration.
• Residential apartments: Single-module control of a room's lighting, shading, and HVAC.
• Commercial spaces: Meeting rooms and individual offices with mixed load types.
• Conventional switches: Connect wall push-buttons to the 8 input channels while actuating loads from the relay outputs — no separate universal interface required.
• Separate actuators: Where only switching or dimming is needed, use the EAE SW108 Switch Actuator or SD110 Dim Actuator.

Choosing EAE Room Control Units

The RCU0808 adds 8 universal inputs to the output-only RCU0800. For 12 outputs choose RCU1200 (output-only) or RCU1212 (with inputs). For output-only at the same 8-relay capacity, see the EAE RCU0800. For 12 relay outputs, choose the RCU1200.

EAE naming: RCUXXYY where XX = output count and YY = input count (0 = output-only). All models share the KNX Room Control Unit v2.0 ETS application.
